AUTOMATIC DIGESTION UNITS

Sample preparation is a crucial part of the Kjeldahl analysis in order to obtain accurate and precise results. The DKL Series digesters are fully automatic units where manual operations have been drastically reduced: lowering and lifting of the samples takes place automatically.

You just need to weigh your sample, add the reagents and catalysts and select the method.

DKL 8	(8 positions for 250 ml test tubes, Ø 42 mm)
DKL 12	(12 positions for both 250 and 400 ml test tubes, Ø 42 mm)
DKL 20	(20 positions for both 250 and 400 ml test tubes, Ø 42 mm)
DKL 42/26	(42 positions for 100 ml test tubes, Ø 26 mm)

Technical Specifications:

	DKL 8	DKL 12	DKL 20	DKL 42/26
CONSTRUCTION MATERIAL	Stainless steel with chemicalresistant coating
LIFT AND SUCTION CAP CONTROL	Automatic
CONTROL SYSTEM	Microprocessor with LCD Graphic Display
TEMPERATURE RANGE	Room temp. to 450°C
TEMPERATURE ACCURACY	± 0.5 °C
SET TEMPERATURE	Digital Readout in °C, °F or K
TEMPERATURE CALIBRATION	Automatic
PROGRAM LIBRARY	54 Program library, including24 user-programmable memories
TEMPERATURE RAMPING	4 ramps per program
TIME SELECTION	1 to 999 Minutes - 1 MinuteSteps
COUNTDOWN	Digital Readout
LANGUAGES	UK, I, E, F, RUS, CN+ Additional downloadable
INTERFACE	USB
RUN COMPLETED ALERT	Visual and Acoustic Signal
DAMAGED TEMPERATURE PROBE	Automatic Detection andAlarm Message
HEATING PLACES	8	12	20	42
SIZE OF TUBES	250 ml	250 ml / 400 ml	250 ml / 400 ml	100 ml
POWER	1150 W	1500 W	2300 W	2300 W
OVERALL DIMENSION (WxHxD)	210x690 x540 mm	266x690 x540 mm	322x690 x584 mm	322x690 x584 mm
OVERALL WEIGHT	19.7 kg	23.3 kg	30.8 kg	33.5 kg

Supporting Materials:

Contact us for pricing
